ACB Panels

Name: ACB Panels
Brand: SERVO TECH CONTROL SYSTEM
Price: 300000.0 INR
Availability: InStock

Price 300000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ACB Panels Specification

Cooling System
Natural Air Cooled

Current Rating
6300A

Rated Current
Up to 6300A

Connectivity Type
Hardwired, Communication ports optional

Cabinet Material
CRCA Sheet Steel

Protection Class
Class 1

Rated Operation Voltage
660V

Protection Level
IP42 / IP52 / IP55 (as required)

Panel Type
ACB Distribution Panel

Cover Material
CRCA Steel with Powder Coating

Thickness
1.6 mm - 2 mm (Sheet Thickness)

Components
Air Circuit Breakers, Indicators, Control Switches, Busbars

Control System
Manual/Automatic

Operating Voltage
415V AC

Base Material
Other

Rated Insulation Voltage
1000V

Features
Modular Construction, High Short Circuit Withstand, Easy Maintenance

Way
Multi Way (Custom Configurable)

Product Type
Air Circuit Breaker (ACB) Panel

Material
Other

Surface Finish
Epoxy Powder Coated

Standard
IEC 61439 / IS 8623

Surface Color
White

Rated Voltage
690V AC

Frequency (MHz)
50/60 Hz

Maximum Output Current
6300A

Dimension (L*W*H)
Custom-built as per site requirements

Application
Power Distribution, Industrial, Commercial

IP Rating
IP42 to IP55

Display Type
Analog / Digital Meters

Metering
MCB/ELCB, Voltmeter, Ammeter, Multifunction Meter

Operating Temperature
-10C to +45C

Panel Configuration
Fixed or Drawout Type

Mounting Type
Floor Mounted

Interlocking
Mechanical & Electrical Interlocks Available

Busbar Support
DMC/SMC Insulator

Paint Type
Polyester/Epoxy Powder Coating

Seismic Compliance
Up to Zone IV

Earthing
Provided as per IS Regulations

Busbar Material
Electrolytic Grade Copper / Aluminum

Cable Entry
Top/Bottom Entry as per requirements

Enclosure Type
Indoor (Outdoor available on request)

Standards Compliance
IS 8623, IEC 60439, IEC 61439

Testing
Routine & Type Tested at NABL Accredited Laboratories

Short Circuit Withstand Capacity
Up to 65 kA for 1 sec

ACB Panels Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
10 Pieces Per Week

Delivery Time
3 Week

Sample Policy
Contact us for information regarding our sample policy

Main Export Market(s)
Asia

Main Domestic Market
Gujarat, Maharashtra, Rajasthan, Madhya Pradesh

About ACB Panels

Relying on profound knowledge and expertise in this industry, we are regarded to be a pioneer manufacturer and supplier of ACB Panels. To manufactured these panels in compliance with industrial standards, we procure fine quality materials and components from reliable vendors of the market. These panels are widely used in electrical industries and popular in the market for their protection relays and greater efficiency. Clients can get ACB Panels from us at market leading prices.

Specification:- 415V AC, 65kA, ICS=ICU @ 100%.

ACB PANEL is used in supply dist. in area,

For More details : Download the PDF file

Product Details of ACB Panels :

Max. Voltage:	415 V
Max. Current	250 A

"We Are Mainly Deal In Gujarat, Maharashtra, Rajasthan"

Superior Safety and Performance

ACB Panels are engineered for rigorous environments, featuring high short-circuit withstand capacity and advanced mechanical and electrical interlocking. Compliance with IS 8623, IEC 60439, and IEC 61439 standards ensures dependable protection and operation. Tested at NABL accredited laboratories, these panels are reliable under demanding industrial and commercial conditions.

Versatile Customization and Modular Design

Available in both fixed and drawout configurations, our panels are highly configurable with multiple busbar materials, mounting options, and tailored dimensional specifications to fit your site requirements. Modular construction supports seamless expansion or maintenance, making them suitable for diverse applications, from factories to commercial complexes.

Comprehensive Protection and Monitoring

Each panel includes integrated earthing in line with IS regulations, metering devices such as MCB/ELCB, ammeters, voltmeters, and multifunction meters. With IP42 to IP55 protection levels and Class 1 insulation, the design prioritizes both operational safety and ease of monitoring through analog or digital displays, ensuring efficient energy management.

FAQ's of ACB Panels:

Q: How are ACB panels tested for safety and compliance?

A: Each ACB panel undergoes routine and type testing at NABL accredited laboratories to ensure safety, performance, and compliance with IS 8623, IEC 60439, and IEC 61439 standards. These tests assess the panel's ability to handle rated currents, withstand short-circuit events up to 65kA, and conform to electrical and environmental requirements.

Q: What are the available material and configuration options for busbars in these panels?

A: ACB panels offer busbars made from electrolytic grade copper or aluminum, with support insulators of DMC/SMC for reliability. Configuration options include both fixed and drawout types, customizable busbar layouts, and multi-way systems tailored to your site's needs.

Q: When should I choose indoor versus outdoor enclosures?

A: Standard ACB panels come with an indoor enclosure. If your installation requires exposure to external weather or harsher environments, outdoor enclosures are available on request. Both options deliver robust protection, with IP ratings from IP42 up to IP55.

Q: Where can the panel be installed and how is it mounted?

A: These panels are designed for floor mounting and can be installed in a variety of settings, including industrial plants, commercial buildings, and power distribution centers. The modular construction allows for easy integration into new or existing power systems.

Q: What is the process for customizing ACB panel dimensions and features?

A: Dimensions (length, width, height) and configurations are fully customizable based on your site's requirements. Features such as metering, interlocks, cable entry location (top or bottom), and protection levels can be tailored during the design phase in collaboration with our technical team.

Q: How do these panels support efficient monitoring and control?

A: ACB panels include MCB/ELCB, voltmeter, ammeter, and multifunction meters, with both analog and digital display options. Mechanical and electrical interlocks, as well as manual or automatic control systems, allow for efficient monitoring, control, and maintenance of your electrical distribution network.

Q: What are the main benefits of installing ACB panels with modular construction and advanced safety features?

A: The modular design ensures easy maintenance, quick upgrades, and adaptability to future expansion. Advanced safety features like high short circuit withstand and comprehensive interlocking provide enhanced operational reliability and personnel protection, making these panels an optimal long-term investment.
