APFC Panel

Name: APFC Panel
Brand: SERVO TECH CONTROL SYSTEM
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

APFC Panel Specification

Way
3 Phase

Cabinet Material
Sheet Metal, Powder Coated

Cooling System
Natural Air / Forced Air Cooling (Optional)

Thickness
2 mm (Cabinet)

Base Material
CRCA Sheet Steel

Current Rating
Subject to design (typically 100A to 6300A)

Cover Material
Powder Coated Steel

Rated Insulation Voltage
Up to 1000V AC

Operating Voltage
415V AC, 3 Phase

Rated Operation Voltage
Up to 690V AC

Connectivity Type
Wired

Rated Current
Up to 6300A

Control System
Microprocessor based / Intelligent PF relay

Protection Class
Class I

Protection Level
Overload, Short-Circuit, Earth Fault

Features
Automatic, Programmable, User Friendly Interface, Low Maintenance

Components
Contactors, Capacitors, PF Relay, Circuit Breakers, Switches

Panel Type
Floor Mounted / Indoor

Product Type
Automatic Power Factor Correction (APFC) Panel

Material
Mild Steel (MS)

Surface Finish
Smooth, Powder Coated

Standard
IEC 61439 / IS 8623

Surface Color
Powder Coated (Beige or Gray)

Rated Voltage
415V AC

Frequency (MHz)
50 Hz

Maximum Output Current
Up to 6300A (Configurable as per requirement)

Dimension (L*W*H)
Customized as per client requirement

Application
Industrial, Commercial, Power Utilities

IP Rating
IP42, IP54 (Customizable)

Display Type
Digital / LED / LCD

Communication Protocol
Optional - Modbus / RS485

Feedback Protection
MCB for each capacitor stage

Control Voltage
230V AC

Operating Environment
-10C to +50C, up to 95% RH non-condensing

Enclosure Type
Indoor/Outdoor application (as specified)

Earthing
Dual earthing provision

Capacitor Type
Heavy Duty, Low Loss, Detuned (if required)

Panel Construction
Modular type, front access for maintenance

Panel Weight
As per design (approx. 150-400 kg)

Busbar Material
Electrolytic Copper / Aluminum (as per design)

Mounting Type
Floor Standing

Metering
Digital VAF meter, Ammeter, Voltmeter

Phase
Three Phase + Neutral

APFC Panel Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
7 Days

About APFC Panel

Presenting our Inestimable, Best-seller APFC Panel, reserved for clients seeking praiseworthy power factor correction solutions. Meticulously engineered with modular construction and front access for effortless maintenance, this panel is designed for floor-standing installations. Offering soaring performance in diverse operating environments (-10C to +50C, 95% RH), it integrates heavy-duty, low-loss capacitors and digital metering for precision. Robust feedback protection and dual earthing ensure safety. Finished in smooth, powder-coated steel, this APFC Panel sets the bar for reliability and efficiency in industrial and commercial power management across India. Reserve yours and redeem unparalleled savings today!

Versatile Performance & Reliable Usage

The APFC Panel is suitable for use across industrial, commercial, and utility sectors where automatic power factor correction is vital. Designed for floor mounting with modular construction, it features a user-friendly, intelligent relay for seamless operation and precise monitoring. Simply connect the panel as per wiring instructions, set the control voltage, and let the automatic system perform continuous adjustments. Ideal for ensuring energy efficiency, reducing penalties, and optimizing power usage in various demanding applications.

Domestic Market Valuation & Swift Shipment Exchange

Our APFC Panel commands high valuation in the Indian domestic market, supported by trusted supply ability and proven manufacturer reliability. Products are ready for shipment across the nation, with a flexible sample exchange policy offered to facilitate product assessment before larger deployments. We ensure prompt shipment, customizable specifications, and a responsive service network that streamlines order exchanges, making us a premier supplier of APFC solutions throughout India.

FAQ's of APFC Panel:

Q: How does the APFC Panel help improve energy efficiency?

A: The APFC Panel automatically regulates the power factor by switching capacitor banks in and out as needed. This reduces line losses, improves voltage stability, and helps cut down on energy bills, ensuring praiseworthy operational efficiency for any facility.

Q: What is the process for installing and commissioning the APFC Panel?

A: Installation involves securing the floor-mounted modular panel, connecting three-phase input/output cables, and configuring the user-friendly control system according to site-specific requirements. Commissioning includes initial testing, operational verification, and programming of the digital metering and protection features.

Q: Where can the APFC Panel be utilized effectively?

A: This panel is ideal for industrial plants, commercial complexes, and power utilities-essentially anywhere consistent, high-load electrical systems require reliable power factor correction and reduced penalty charges.

Q: What are the main features and user benefits of this APFC Panel?

A: Key features include a modular design, heavy-duty low-loss capacitors, precise digital metering, comprehensive overload and earth fault protection, and robust construction. Users benefit from low maintenance, programmable functionality, and compatible operation in harsh environments.

Q: When should I consider upgrading or replacing an existing power factor correction panel?

A: Upgrade when your facility experiences increased electrical loads, decreased efficiency, or frequent power factor penalties. The new APFC Panel offers soaring performance, safety improvements, and compliance with current standards, making it a worthy exchange for outdated systems.
